EVERWIN HR77XE CL24 HOG RING PLIER 70MM NOSE

EVERWIN HR77XE HOG RING PLIER (EXTRA LONG NOSE)

An industrial 15 GA pneumatic hog ringer with an extra-long nose, built for high-volume fastening in packaging, seating, fencing, and insulation. Compatible with Bostitch RING15 / Meihotech GDH rings, it features pneumatic piston return for faster cycles and can be integrated with zero balancer and manifold kits for production lines.

Features

• Extra-long nose for access to hard-to-reach areas

• Pneumatic piston return reduces cycle time

• Adjustable for left- or right-handed operation

• Durable all-metal build for industrial environments

Applications

• Large bag closure (concrete, powders, liners)

• Car & boat seat upholstery

• Poultry/produce mesh bags

• Wire cages & fencing

• Insulation (heat & sound)

• Netting, rope, bungee fastening

• Bedding (flange to spring)

Specifications

• Weight: 1.39 kg (3.0 lbs)

• Dimensions (LxWxH): 381 x 89 x 189 mm

• Operating Pressure: 5.9–7.9 bar (85–115 psi)

• Air Consumption: 0.5 L/sec @ 90 psi (1.05 cfm)

• Capacity: 100 rings

• Fasteners: 15 GA RING15 / GDH rings (12 mm height, 23.9 mm crown, 1.8 mm wire)
